Advantages
- High volume air flow combined with full dispersion due to the rotation of the equipment at a high speed, results in a high coating rate and ensures no dead zone.
- The adjustable grinding device is suited for the coating of powder from 325 to 3000 mesh and has a wide distribution of particle sizes.
- An external heating device featuring a controllable temperature, providing a stable product.
- Precise metering spraying device enables automation and uses fewer modifiers in production.
- External induced draft fan can be adjusted to alter the coating time, thus accommodating different types of modifiers.
Technical Parameters
| Parameter | 300 | 500 | 750 | 1000 | 1250 | 1500 |
| Grinding disc rotate speed (rpm) | 7350 | 4530 | 2820 | 2320 | 1850 | 1550 |
| Max. grinding disc linear speed (m/s) | 115.5 | 114.0 | 118.1 | 121.8 | 121.5 | 121.7 |
| Grinding disc power (kW) | 22 | 45 | 90 | 110 | 132~160 | 160~200 |
| Max. air flow (m³/h) | 1200 | 2100 | 3300 | 4500 | 5100 | 6500 |
ALPA is a highly respected name in particle and powder processing, transforming the way the industry views traditional powder processing. Our research and development initiatives have focused on dry grinding, classification and separation, powder shape control and surface modification of particles and powders over the past two decades. As a result, we are proficient in providing tailored, CE-certified products, such as air jet mills, mechanical mills, air classifiers, ball mill with classifier, surface modification lines and more.
